Mahaveer Steel is a maker, wholesaler, exporter, and provider of thorough reach SS 316/316L items. We are providing the most subjective scope of SS 316/316L Sheet Plates. SS 316 is the most generally utilized sort of Stainless Steel for the creation of various items. SS316L is a lower carbon adaptation of Stainless Steel, which is generally useful for Plate producing. We are picking crude material in the wake of testing it to keep up with quality higher.
We are manufacturing SS 316/316L Sheet Plates in different sizes, grades, and measurements. We additionally make altered and non-redid structures. These Plates have incredible protection from erosion in numerous natural conditions. Our devoted groups and quality specialists are striving to convey anticipated that quality should our regard customers. By thinking about the requirements of our customers, we are creating entirely coordinating with Plates.
We, Mahaveer Steel, are understanding the significance of value and exact items. Thus, we test the interaction from the determination of material till the last dispatch of the Plates. Our master performs numerous tests to check the quality and different boundaries. According to global and public quality principles, we guarantee all guidelines of SS 316/316L Sheet Plates. With rigidity, levelness, surface, and consumption obstruction, our Plates offers various highlights that make them reasonable to use in mechanical applications.
We have received the furthest down the line innovation to meet the upgrading assumptions for our customers. With the utilization of cutting edge hardware, we are delivering SS 316/316L Sheet Plates in mass sum. This makes us ready to convey Plates in the necessary sum. Mahaveer Steel is providing items in different materials and sizes. We are zeroing in on to give a totally coordinating with SS 316/316L Sheet Plates at moderate rates with fantastic wrapping up.
Specification : ASTM A240 / ASME SA240
Dimension Standard : JIS, AISI, ASTM, GB, DIN, EN, etc
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Thickness : 0.3 mm to 120 mm
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Surface Finishing : Hot rolled plate (HR), Cold rolled sheet (CR),2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, Chequered, embossed, hair line, sand blast, Brush, etching, SATIN (Met with Plastic Coated) etc.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | - | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
| SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
| SS 316Ti | 1.4539 | N08904 | SUS 316Ti | 904S13 | STS 317J5L | Z2 NCDU 25-20 | X1NiCrMoCu25-20-5 |
All Sheets and Plates is manufactured and tested / inspected to the relevant standards including ASTM, ASME and API etc.
| Stainless Steel Gauge Width and Length | Weight Lbs. per Sq. Ft. | Estimated Weight per Sheet |
|---|---|---|
| 7 ga. (.1874") x 48 x 120 | 7.871 | 314.8 |
| 10 ga. (.135") x 48 x 120 | 5.670 | 226.8 |
| 11 ga. (.120") x 36 x 120 | 5.040 | 151.2 |
| 11 ga. (.120") x 48 x 96 | 5.040 | 161.3 |
| 11 ga. (.120") x 48 x 120 | 5.040 | 201.6 |
| 11 ga. (.120") x 48 x 144 | 5.040 | 241.9 |
| 11 ga. (.120") x 60 x 96 | 5.040 | 252.0 |
| 12 ga. (.105") x 36 x 120 | 4.410 | 132.3 |
| 12 ga. (.105") x 48 x 120 | 4.410 | 176.4 |
| 12 ga. (.105") x 60 x 120 | 4.410 | 220.5 |
| 14 ga. (.075") x 36 x 120 | 3.150 | 94.50 |
| 14 ga. (.075") x 48 x 120 | 3.150 | 126.0 |
| 16 ga. (.060") x 36 x 120 | 2.520 | 75.60 |
| 16 ga. (.060") x 48 x 96 | 2.520 | 80.64 |
| 16 ga. (.060") x 48 x 120 | 2.520 | 100.8 |
| 16 ga. (.060") x 60 x 120 | 2.520 | 126.0 |
| 18 ga. (.048") x 36 x 120 | 2.016 | 60.48 |
| 18 ga. (.048") x 48 x 120 | 2.016 | 80.64 |
| 20 ga. (.036") x 36 x 120 | 1.512 | 45.36 |
| 20 ga. (.036") x 48 x 120 | 1.512 | 60.48 |
| 22 ga. (.030") x 36 x 120 | 1.260 | 37.80 |
| 22 ga. (.030") x 48 x 96 | 1.260 | 40.32 |
| 22 ga. (.030") x 48 x 120 | 1.260 | 50.40 |
| 24 ga. (.024") x 36 x 120 | 1.008 | 30.24 |
| 24 ga. (.024") x 48 x 120 | 1.008 | 40.32 |
| 26 ga. (.018") x 36 x 120 | .7560 | 22.68 |
| 26 ga. (.018") x 48 x 120 | .7560 | 30.24 |
| 28 ga. (.015") x 36 x 120 | .6300 | 18.90 |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 - 18.00 | 2.00 - 3.00 | 11.00 - 14.00 | 67.845 min |
| SS 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 - 18.00 | 2.00 - 3.00 | 10.00 - 14.00 | 68.89 min |
| SS 316Ti | 0.020 max | 2 max | 1.0 max | 0.040 max | 0.030 max | 19-23 | 4.00-5.00 | 23.00-28.00 | - |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SS 316 / 316L | 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| SS 316Ti | 7.95 g/cm3 | 1350 °C (2460 °F) | Psi – 71000 , MPa – 490 | Psi – 32000 , MPa – 220 | 35 % |
